Art.-No. 78185

fischer Expansion plug SX 6 x 50 R with wide rim and larger anchorage depth

Name: fischer Expansion plug SX 6 x 50 R with wide rim and larger anchorage depth
Brand: fischer

Product variants

CAD Data

Download of image data

Top Features

Optimum force transmission due to four-way expansion. This allows for high holding values in solid and hollow building materials.
Simple to assemble: The edge of the plug prevents it from falling deeper into the drill hole.
No expansion pressure on the plug neck. This means that tiles or plaster are not damaged.
Greater anchorage depth: better force transition in hollow building materials and aerated concrete.

The powerful nylon fixing with four-way expansion and larger anchoring depth.

Advantages

The 4-way expansion provides the optimum force distribution in the material, and offers high load-bearing capacities in solid and hollow building materials.
The expansion-free plug neck prevents the creation of expansion forces on the material surface whilst screwing in the screw. This helps to prevent damage to tiles and plaster.
The pronounced rim prevents the plug from slipping into the drill hole, thus allowing for a simple installation.
The greater anchorage depth means that the plug is especially suited to fixings in hollow building materials, aerated concrete and to bridge plaster.

The fischer expansion plug SX transfers force optimally in the building material through the 4-way expansion. Apart from the typical expansion, the high-quality nylon used for its production guarantees secure and permanent fixing. The preshaped edge on the plug head prevents the plug from slipping into the drill hole. This variant, with larger anchorage depths, is Ideal for fixings in hollow building materials, in aerated concrete and for plaster covering.

Applications

Lighting
Motion detectors
Skirting
Letter boxes
Trellis

Building materials

Concrete
Vertically perforated brick
Hollow blocks made from lightweight concrete
Cavity floor slabs made from bricks and concrete
Perforated sand-lime brick
Solid sand-lime brick
Natural stone with dense structure
Aerated concrete
Solid panel made from gypsum
Solid brick made from lightweight concrete
Solid brick

You can find detailed information on building materials in the registration document.

Functionality

The rimless SX is suitable for push-through installation.
When turning in the screw, the SX expands in four directions, thus providing a secure anchoring in the building material.
The required screw length is given by: Plug length + fixture thickness + 1 x screw diameter.
Suitable for wood, chipboard and spacing screws fischer ASL.

Mounting Strip 1 Picture

1 / 4

Drill diameter ( d₀ )	6 mm
Min. drill hole depth ( h₁ )	60 mm
Anchor length ( l )	50 mm
Wood and chipboard screws ( d_s )	4.0 - 5.0 mm
Amount	100 pcs.
Packaging	Folding box
GTIN (EAN-Code)	4006209781852
