Thread hanger RAH
  • Product Picture: "fischer Thread hanger RAH M10"
    • Product Picture
      Art.-No. 79699

      fischer Thread hanger RAH M10

      Product variants
      CAD Data
      Download of image data
      Top Features
      • Simple to assemble.
      • With internal thread connection.
      • Made of zinc-galvanised steel.

      The advantages / Product description

      Universal thread hanger with internal thread connection.
      The fischer thread hanger RAH is a fastening element made from zinc-plated steel. These are used as connector elements for attaching pipes.
      Properties
      • Material: 11SMnPb30 (material no. 1.0718) acc. to DIN EN 10087
      • Zinc plating: electro zinc-plated

      Application and approval

      Applications
      • For use in dry interior areas.

      Assembly instruction

      Functionality

      Technical data

      Thread (
      A
      )      		M10
      Hole-ø (
      D
      )      		12 mm
      Max. recom. static load (centr. tension) (
      Nrec
      )      		4 kN
      Amount 50 pcs.
      GTIN (EAN-Code) 4006209796993
